XT16HR East West
The 16ft Powerhouse
Top Features
Dimensions & Weights
TONGUE WEIGHT
Approx. 615 lbs
GVWR
6147 lbs
CURB WEIGHT
Approx. 5550 lbs
Model Features
Interior Features
Exterior Features
Electrical Features
Explore the model
Model Specifications
COLD WEATHER PACK DESIGN
♦ Water tank heating pads
♦ Truma AquaGo HWS electric anti-freeze kit
♦ RENOGY REGO battery with intelligent self-heating function
♦ Insulated water lines
♦ Wet bay with interior space heating
♦ Thetford Cassette toilet with integrated flush tank
♦ Truma VarioHeat 11,500 BTU/h Furnace
♦ Dual Pane Windows
GENERAL
♦ Sleeps 3
♦ 16’ Overland Travel Trailer
♦ 1 x custom pillow-top queen size innerspring mattress
♦ Mattress – 83″ L x 62″ W x 9″ H
♦ Galvanised chassis + external aluminum composite panel
♦ Combination of welded aluminum 2″ x 1″ and 3″ x 1″ hot rolled rectangle tube and 1″ x 1″ square aluminum alloy
DIMENSIONS
♦ Open – 21’6″ L x 14’3″ W x 10′ H
♦ Closed – 21’6″ L x 7’8″ W x 10′ H
♦ Annex Size – 17’8″ x 6’7″
♦ Shower Tent Size – Approx. 4′ x 4′
WEIGHTS & RATINGS
♦ Dry weight Approx. 5550 lbs
♦ Tongue weight Approx. 615 lbs
♦ GVWR 6147 lbs
♦ Cargo Carrying Capacity Approx. 597 lbs
CHASSIS
♦ 5″ x 2″ – Galvanized steel hot rolled rectangle tube
♦ Cruisemaster™ DO35 hitch
♦ ARK XO750 Jockey Wheel
♦ 16 x 7.5 6/139.7 Aluminum alloy wheels fitted with 265/75R16 Goodride MT tires, 1 x spare wheel & rear mounted external step/service ladder
♦ X-TRACK Independent coil spring suspension with 2x TOUGH TRAX HD Shock absorbers on each side
♦ 12″ electromagnetic brakes with handbrake and drawbar mounted emergency breakaway system
♦ 4 x heavy duty lockable and adjustable drop down stabilizer legs
♦ Integrated jacking points on suspension and chassis rails
EXTERIOR
♦ 13.8′ 12V electric cassette awning
♦ Full annex, enclosed roof, walls, floor and draft skirt
♦ 2 x 20lbs propane cylinder and cylinder holders
♦ 2 x 5 gallon jerry can holders
♦ 2 x 21 gallon fresh water tanks + 1 x 21 gallon grey water tank
♦ 12V electric marine diaphragm pump
♦ Internal Modern oak timber style laminated bench & counter tops with black matte finished sink & faucets
♦ Slide out stainless steel body with gas hob cooktop & sink with plumbed hot & cold water supply
♦ Front-mounted chequer plate 3 bay utility box with forward-facing mud flap protection
♦ Fridge Slide – 40¾” L x 21½” W x 18½” H
♦ Hot/cold external shower includes wall-mounted shower tent
♦ Wall-mounted drop-down servery table & inside/outside rolling pantry (pass through storage hatch)
INTERIOR
♦ Full bathroom with Thetford C224-CW Cassette toilet and separate hot & cold plumbed shower
♦ Tinted slimline dual pane acrylic windows and double cassette blind with flyscreen and block-out
♦ Bathroom 12V roof hatch with fan and LED lighting and skylight over the bed with 12V lighting and double cassette blind
MAJOR APPLIANCES
♦ Truma Aventa Eco 13,500 BTU/h roof-mounted air conditioning system
♦ Truma AquaGo Comfort Plus instant hot water system (propane-operated)
♦ 5.3 cu ft. Norcold N2152 12/24V compressor refrigerator
♦ Internal FURRION 21″ RV 3-Burner Gas Oven Range
♦ External Thetford stainless steel 3-burner gas hob cooktop with glass lid
♦ Truma VarioHeat 11,500 BTU/h propane operated furnace
♦ FURRION 0.9 cu.ft. 900W Microwave
SAFETY FEATURES
♦ Tuson TSC-1000 – electronic stability control with asymmetric braking (offroad ready)
♦ 2.4GHz digital wireless rear view camera + 7″ portable monitor
♦ MDC-LOK® – coupling lock
ELECTRICAL
♦ 800Ah of Renogy REGO 12V Lithium Iron Phosphate battery capacity
♦ 4 x 175W Solar Panels (700W Total) with SolarAirâ„¢ – Thermal Management solar panel mounting system 1
♦ Renogy DCC30S 12V 30A DC-DC On-Board Battery Charger
♦ Renogy REGO 60A MPPT Dedicated Solar Charge Controller
♦ Renogy REGO 150A AC Smart Battery Charger
♦ Renogy REGO 3000W 12V Pure Sine Wave HF Inverter
♦ Renogy ONE Core – Monitoring System
♦ 12V LED lighting throughout with wireless switching
♦ 12V LED lighting throughout, awning and offside white and yellow (Bug Light) wall lighting with light up entry door grab handle, position markers, indicator & stop/tail lights
♦ 7-way trailer connector (SAE J2863 type) + 1 x 50A Anderson plug
♦ Stereo head unit with internal & external speakers
♦ HD LED TV with 12V compatibility, USB and Internal & External full motion TV brackets
♦ Milenco Power 900L omnidirectional TV antenna
♦ 2 x Caframo Sirocco II 12V wall-mounted 3-speed fan
INTERNAL POWER OUTLETS
♦ 12V accessory sockets
♦ 5V dual USB charging ports
♦ 110V receptacles
♦ F-type TV outlet
♦ 10W wireless countertop built-in phone chargers
EXTERNAL POWER OUTLETS
♦ 12V accessory sockets
♦ 110V receptacles
♦ F-type TV outlet
♦ Anderson plug
